Threaded Nozzles

1/4” MPT NOZZLES (hardened stainless steel)
Ideal for one nozzle applications and quick exchange is not needed

ORIFICE 0° 5° 15° 25° 40° 50° 65°
SIZE
1.0 — — — 820202501 820204010 — —
1.5 — — — 820202515 — — —
2.0 820200020 — 820201520 820202520 820204020 — 820206502
3.0 820200003 — 820201530 820202530 820204030 — 820306530
3.5 820200035 — 820201535 820202535 820204035 — —
4.0 820300004 820300504 820301540 820302540 820304040 — 820306540
4.5 820400045 — 820401545 820402545 820404045 — 820406545
5.0 820500005 — 820501550 820502550 820504050 — 820506550
5.5 820600055 — 820601555 820602555 820604055 — 820606555
6.0 820700006 — 820701560 820702560 820704060 820705060 820706560
6.5 820700065 — 820701565 820702565 820704065 — —
7.0 820800007 — 820801570 820802570 820804070 — —
7.5 — — 820801575 — — — —
8.0 820900008 — 820901580 820902580 820904080 — 820906508
9.0 — — 820901509 — 820904090 820905090 820906509
10.0 821000010 — 821001510 821002510 821004010 — 821006510
11.0 — — 821001511 — — — —
12.0 821000012 821500512 821001512 821002512 821004012 — —
15.0 821000015 821500515 821001515 821002515 821504015 — 821006515
20.0 821000020 821500520 821501520 821002520 821504020 821005020 821006520
25.0 821500025 — 821501525 821502525 821004025 — —
30.0 821000030 821500530 821601530 821002530 821604030 — 821006530
35.0 821000035 — 821001535 821002535 821604035 — —
40.0 821000040 — 821001540 821002540 821004040 — 821006530
50.0 821000050 — — — 821004050 — —
60.0 821000060 821500560 — 821002560 — — —
• Spray angles range from high impact solid stream 0° to 65° flat spray
• Produce an uniform distribution of small to medium sized drops

1/4” MPT VEEJET NOZZLES (brass)
Ideal for one nozzle applications and when quick exchange is not needed
ORIFICE 0° 15° 25° 40° 50° 65° 80°
SIZE
10.0 — — 8110S2510 8110S4010 — — —
stainless
steel 15.0 — — 8110S2515 — — — —
20.0 8110S0020 8110S1520 8110S2520 8110S4020 — — 8110S8020
30.0 8110S0030 820051530 8110S2530 8110S4030 — — —
40.0 — — 8110S2540 — — 8110S6540 —
50.0 8110S0050 — 8110S2550 8110S4050 8120S5050 — —
60.0 8110S0060 — 8110S2560 8110S4060 — — —
brass 70.0 — — 8110S2570 — — — —

ALSO AVAILABLE:
ORIFICE SIZE 25° 65° 110°
1.0 — — 811S11001 (S.S)
10.0 812SS2510 (S.S) 8110S6510 (B.R) —
• High impact spray pattern
