Threaded Nozzles

1/8” MPT NOZZLES (hardened stainless steel)
Ideal for one nozzle applications and quick exchange is not needed

ORIFICE 15° 25° 40° 50° 65°
SIZE
1.0 828001501 — — — —
1.5 828015015 — — — —
2.0 — 828025020 — — 828506520
2.5 828015025 — — — —
3.0 828201530 — 828404030 — —
3.5 828015035 — — — —
4.0 828401540 828402540 828404040 — —
4.5 828401545 828402545 — — —
5.0 828601550 — — 828505050 828506550
5.5 828601555 — — — —
6.0 — 828602560 — — —
6.5 828601565 828602565 — — —
7.0 — 828702570 — 828505070 —
8.0 — — — — 828506580
10.0 — — 828104010 — —
15.0 828501515 — — — —
• Spray angles range from high impact solid stream 15° to 65° flat spray
• Produce a uniform distribution of small to medium sized drops
ALSO AVAILABLE:
15° Soap (brass)

ORIFICE 15° (Soap)
SIZE
15.0 828BR1515
50.0 828BR5050

*Minimal quantities required for special order nozzles

1/4” FPT NOZZLES (hardened stainless steel)
Ideal for one nozzle applications and when quick exchange is not needed
ORIFICE SIZE 0° 15° 25° 40°
4.0 9WEG0D040 — 9WEG25040 —
4.5 — 9WEG15045 9WEG25045 9WEG40045
5.0 9WEG0D005 9WEG15050 9WEG25050 9WEG40050
5.5 9WEG0D055 9WEG15055 9WEG25055 9WEG40055
6.0 9WEG0D006 — — 9WEG40060
7.0 — 9WEG15070 9WEG25070 9WEG40070
8.0 9WEG0D008 9WEG15080 9WEG25080 9WEG40080
9.0 — 9WEG15090 9WEG25090 9WEG40090
10.0 9WEG00D10 9WEG01510 9WEG02510 9WEG04010
• Spray angles range from high impact solid stream 0° to a 40°
