P. 14

Rear Entry Spray Guns





                                ST-1500 STAINLESS STEEL SPRAY GUN
                                Industry standard, the ST-1500 is well-suited for a
                                variety of industrial pressure washing applications
                                 ORDER #    PRESSURE TEMP.     FLOW RATE   INLET   OUTLET   WEIGHT   BOX QTY
                                 201500911   5000 PSI  300° F   10.4 GPM   3/8" FPT 1/4" FPT  1.24 lb   50
                                                                                       Repair Kit: #201500496
                                •  Industry Standard - well-suited for a variety of industrial
                LFT               pressure washing applications
                LFT
                                •  Unitized valve for easy repair
                                •  Stainless steel spring, needle, ball and seat
                                •  Stainless steel outlet, inlet connection, including inlet pipe
                                •  Fully rebuild-able
                                •  LFT (Low Friction Trigger) this gun’s trigger system incorporates
                                  a ball between the trigger and piston rod contact area that rolls
                                  when triggered resulting in a much easier opening and holding




                                ST-2000 SPRAY GUN (extreme duty)
                                Our most popular industrial production gun, the ST-2000 is designed for
                                heavy-duty durability. The strongest made gun in it's class takes the abuse.
                                 ORDER #    PRESSURE TEMP.     FLOW RATE   INLET   OUTLET   WEIGHT   BOX QTY
                                 202000920   5000 PSI  300° F   10.4 GPM   3/8" FPT 1/4" FPT  1.64 lb   35
                                                                                       Repair Kit: #201500496
                                •  Stainless steel spring, needle, ball and seat
                                •  Forged brass housing for maximum strength
                LFT
                LFT             •  Unitized valve for easy repair
                                •  Suttner’s “Big Hand” spray gun
                                •  LFT (Low Friction Trigger) this gun’s trigger system incorporates
                                   a ball between the trigger and piston rod contact area that rolls
                                   when triggered resulting in a much easier opening and holding



                                ST-2012 SPRAY GUN (ergonomic design)

                                This unique design also reduces wear to a minimum on the internal components
                                 ORDER #    PRESSURE TEMP.     FLOW RATE   INLET   OUTLET   WEIGHT   BOX QTY
                                 202012605   5000 PSI  302° F   10.5 GPM   3/8" FPT 1/4" FPT  1.25 lb   45
                                                                                       Repair Kit: #201500496
                                •  Comfortable grip and reduces fatigue for longer working hours
                                •  This unique design reduces wear to a minimum on the internal components
                                •  Great choice for hot and cold pressure washer use
             LFT    PL PL       •  Same inlet & outlet angles as our ST-1500 & ST-2000 spray guns
             LFT
                                •  LFT (Low Friction Trigger) this gun’s trigger system incorporates a ball
                                  between the trigger and piston rod contact area that rolls when triggered
                                  resulting in a much easier opening and holding
                                •  30% less vibration transfer than standard trigger guns when being used
                                  with turbo nozzles, telescopic lanes, sand blasters, etc
                                •  Requires about 13% less squeeze force than a standard trigger gun to
                                  open and hold the trigger. In addition, it has less back force while spraying
                                  due to the optimum hand position


     14       SUTTNER AMERICA COMPANY
